| 型号 | 颜色 | 耗电量（W） | SAG* | 外观图 | |
|---|---|---|---|---|---|
| MDHM-32/32HRT | R | 1.5 | 74 |  |
|
| MDHM-32/32DWT | DW | 1.8 | FF | ||
| MDHM-32/32□T | B | G | 1.8 | DC | |
| MDHM-32/62HRT | R | 2.9 | 75 |  |
|
| MDHM-32/62DWT | DW | 3.6 | FF | ||
| MDHM-32/62□T | B | G | 3.6 | DD | |
| MDHM-32/92HRT | R | 4.4 | 75 |  |
|
| MDHM-32/92DWT | DW | 5.4 | FF | ||
| MDHM-32/92□T | B | G | 5.4 | E0 | |
| MDHM-32/122HRT | R | 5.8 | 76 |  |
|
| MDHM-32/122DWT | DW | 7.2 | FF | ||
| MDHM-32/122□T | B | G | 7.2 | E3 | |
| MDHM-62/62HRT | R | 5.8 | 76 |  |
|
| MDHM-62/62DWT | DW | 7.2 | FF | ||
| MDHM-62/62□T | B | G | 7.2 | E3 | |
| MDHM-62/92HRT | R | 8.7 | 76 |  |
|
| MDHM-62/92DWT | DW | 10.8 | FF | ||
| MDHM-62/92□T | B | G | 10.8 | E8 | |
| MDHM-62/122HRT | R | 11.6 | 77 |  |
|
| MDHM-62/122DWT | DW | 14.4 | FF | ||
| MDHM-62/122□T | B | G | 14.4 | E0 | |
| MDHM-92/92HRT | R | 13 | 78 |  |
|
| MDHM-92/92DWT | DW | 16.2 | FF |  |
|
| MDHM-92/92□T | B | G | 16.2 | E6 | |
| MDHM-92/122HRT | R | 17.3 | 79 |  |
|
| MDHM-92/122DWT | DW | 21.6 | FF | |
|
| MDHM-92/122□T | B | G | 21.6 | ED | |
| MDHM-122/122HRT | R | 23.1 | 7B |  |
|
| MDHM-122/122DWT | DW | 28.8 | FF |  |
|
| MDHM-122/122□T | B | G | 28.8 | F3 | |
○□里，B = 蓝色，G =绿色 ○输入电压是DC12V，也能做DC24V产品
*SAG电源的最大电压设定值，具体信息请参考这里.
