• LIGHTING
  • MDHM series

Very bright chip LED surface-emitting lighting

FEATURES



SPECIFICATION

Model Color Power Consumption (W) SAG* Dimensions
MDHM-32/32HRT R 1.5 74 sMDHM-32-32HRT
MDHM-32/32DWT DW 1.8 FF
MDHM-32/32□T B G 1.8 DC
MDHM-32/62HRT R 2.9 75 sMDHM-32-62HRT
MDHM-32/62DWT DW 3.6 FF
MDHM-32/62□T B G 3.6 DD
MDHM-32/92HRT R 4.4 75 sMDHM-32-92HRT
MDHM-32/92DWT DW 5.4 FF
MDHM-32/92□T B G 5.4 E0
MDHM-32/122HRT R 5.8 76 sMDHM-32-122HRT
MDHM-32/122DWT DW 7.2 FF
MDHM-32/122□T B G 7.2 E3
MDHM-62/62HRT R 5.8 76 sMDHM-62-62HRT
MDHM-62/62DWT DW 7.2 FF
MDHM-62/62□T B G 7.2 E3
MDHM-62/92HRT R 8.7 76 sMDHM-62-92HRT
MDHM-62/92DWT DW 10.8 FF
MDHM-62/92□T B G 10.8 E8
MDHM-62/122HRT R 11.6 77 sMDHM-62-122HRT
MDHM-62/122DWT DW 14.4 FF
MDHM-62/122□T B G 14.4 E0
MDHM-92/92HRT R 13 78 sMDHM-92-92DWT
MDHM-92/92DWT DW 16.2 FF sMDHM-92-92HRT
MDHM-92/92□T B G 16.2 E6
MDHM-92/122HRT R 17.3 79 sMDHM-92-122HRT
MDHM-92/122DWT DW 21.6 FF sMDHM-92-122HRT
MDHM-92/122□T B G 21.6 ED
MDHM-122/122HRT R 23.1 7B sMDHM-122-122DWT
MDHM-122/122DWT DW 28.8 FF sMDHM-122-122HRT
MDHM-122/122□T B G 28.8 F3

● B = Blue, G= Green, in ☐.
● Input voltage is DC12V, but we can also make DC24V products.
● DC24V models have HV at end of the model number.
* SAG is the maximum voltage setting for a SAG power supply. See details here.
