| ＵＶ Cut Fiter （Protection cover filter） | |||
|---|---|---|---|
 |
Model | Filter | Screw Pitch |
| UV225 | UV−CUT | M22.5 P=0.5 | |
| UV255 | UV−CUT | M25.5 P=0.5 | |
| UV270 | UV−CUT | M27.0 P=0.5 | |
| UV305 | UV−CUT | M30.5 P=0.5 | |
| IR Cut Fiter | |||
|---|---|---|---|
 |
Model | Filter | Screw Pitch |
| IR225 | IR−CUT | M22.5 P=0.5 | |
| IR255 | IR−CUT | M25.5 P=0.5 | |
| IR270 | IR−CUT | M27.0 P=0.5 | |
| IR305 | IR−CUT | M30.5 P=0.5 | |
| ND Fiter | |||
|---|---|---|---|
 |
Model | Filter | Screw Pitch |
| ND2225 | ND2(50％) | M22.5 P=0.5 | |
| ND2255 | ND2(50％) | M25.5 P=0.5 | |
| ND2270 | ND2(50％) | M27.0 P=0.5 | |
| ND2305 | ND2(50％) | M30.5 P=0.5 | |
| ND2405 | ND2(50％) | M40.5 P=0.5 | |
| ND4225 | ND4(25%) | M22.5 P=0.5 | |
| ND4255 | ND4(25%) | M25.5 P=0.5 | |
| ND4270 | ND4(25%) | M27.0 P=0.5 | |
| ND4305 | ND4(25%) | M30.5 P=0.5 | |
| ND4405 | ND4(25%) | M40.5 P=0.5 | |
| ND8270 | ND8(12.5%) | M27.0 P=0.5 | |
| ND8305 | ND8(12.5%) | M30.5 P=0.5 | |
| Polarized Fiter | |||
|---|---|---|---|
 |
Model | Filter | Screw Pitch |
| PL255R | PL255 Rotation type | M25.5 P=0.5 | |
| PL270R | PL270 Rotation type | M27.0 P=0.5 | |
| PL305R | PL305 Rotation type | M30.5 P=0.5 | |
| PL340R | PL340R Rotation type | M34.0 P=0.5 | |
| PL355R | PL355R Rotation type | M35.5 P=0.5 | |
| PL375R | PL375R Rotation type | M37.5 P=0.5 | |
| PL405R | PL405R Rotation type | M40.5 P=0.5 | |
| PL430R | PL430R Rotation type | M43.0 P=0.75 | |
| PL460R | PL460 Rotation type | M46.0R P=0.75 | |
| PL490R | PL490R Rotation type | M49.0 P=0.75 | |
| PL520R | PL520R Rotation type | M52.0 P=0.75 | |
| PL550R | PL550R Rotation type | M55.0 P=0.75 | |
| PL580R | PL580R Rotation type | M58.0 P=0.75 | |
| PL620R | PL620R Rotation type | M62.0 P=0.75 | |
| PL670R | PL670R Rotation type | M67.0 P=0.75 | |
| PL720R | PL720R Rotation type | M72.0 P=0.75 | |
| PL770R | PL770R Rotation type | M77.0 P=0.75 | |
| PL820R | PL820R Rotation type | M82.0 P=0.75 | |
| PL950R | PL950R Rotation type | M95.0 P=0.75 | |
| PL106R | PL106R Rotation type | M106.0 P=1.0 | |
| Color Fiter | |||
|---|---|---|---|
 |
Model | Filter | Screw Pitch |
| B225 | Blue | M22.5 P=0.5 | |
| B255 | Blue | M25.5 P=0.5 | |
| B270 | Blue | M27.0 P=0.5 | |
| B305 | Blue | M30.5 P=0.5 | |
| G225 | Green | M22.5 P=0.5 | |
| G255 | Green | M25.5 P=0.5 | |
| G270 | Green | M27.0 P=0.5 | |
| G305 | Green | M30.5 P=0.5 | |
| Y225 | Yellow | M22.5 P=0.5 | |
| Y255 | Yellow | M25.5 P=0.5 | |
| Y270 | Yellow | M27.0 P=0.5 | |
| Y305 | Yellow | M30.5 P=0.5 | |
| R225 | Red | M22.5 P=0.5 | |
| R255 | Red | M25.5 P=0.5 | |
| R270 | Red | M27.0 P=0.5 | |
| R305 | Red | M30.5 P=0.5 | |
| R405 | Red | M40.5 P=0.5 | |
○Please contact us for different filters, not listed on the catalogue.
