• ATTACHMENT

Filter

FEATURES

SPECIFICATION

UV Cut Filter (Protection cover filter)
filter01_2 Model Filter Screw Pitch
UV225 UV−CUT M22.5 P=0.5
UV255 UV−CUT M25.5 P=0.5
UV270 UV−CUT M27.0 P=0.5
UV305 UV−CUT M30.5 P=0.5
IR Cut Filter
filter02 Model Filter Screw Pitch
IR225 IR−CUT M22.5 P=0.5
IR255 IR−CUT M25.5 P=0.5
IR270 IR−CUT M27.0 P=0.5
IR305 IR−CUT M30.5 P=0.5
ND Filter
filter04 Model Filter Screw Pitch
ND2225 ND2(50%) M22.5 P=0.5
ND2255 ND2(50%) M25.5 P=0.5
ND2270 ND2(50%) M27.0 P=0.5
ND2305 ND2(50%) M30.5 P=0.5
ND2405 ND2(50%) M40.5 P=0.5
ND4225 ND4(25%) M22.5 P=0.5
ND4255 ND4(25%) M25.5 P=0.5
ND4270 ND4(25%) M27.0 P=0.5
ND4305 ND4(25%)  M30.5 P=0.5
ND4405 ND4(25%) M40.5 P=0.5
ND8270 ND8(12.5%) M27.0 P=0.5
ND8305 ND8(12.5%) M30.5 P=0.5
Polarized Filter
filter03 Model Filter Screw Pitch
PL255R-M1.4

Rotation type

LIGHTING

M25.5 P=0.5
PL270R-M1.4 M27.0 P=0.5
PL305R-M1.4 M30.5 P=0.5
PL340R-M1.4 M34.0 P=0.5
PL355R-M1.4 M35.5 P=0.5
PL375R-M1.4 M37.5 P=0.5
PL405R-M1.4 M40.5 P=0.5
PL430R-M1.4 M43.0 P=0.75
PL460R-M1.4 M46.0R P=0.75
PL490R-M1.4 M49.0 P=0.75
PL520R-M1.4 M52.0 P=0.75
PL550R-M1.4 M55.0 P=0.75
PL580R-M1.4 M58.0 P=0.75
PL620R-M1.4 M62.0 P=0.75
PL670R-M1.4 M67.0 P=0.75
PL720R-M1.4 M72.0 P=0.75
PL770R-M1.4 M77.0 P=0.75
PL820R-M1.4 M82.0 P=0.75
PL950R-M1.7 M95.0 P=1.0
Color Filter
filter05 Model Filter Screw Pitch
B225 Blue M22.5 P=0.5
B255 Blue M25.5 P=0.5
B270 Blue M27.0 P=0.5
B305 Blue M30.5 P=0.5
G225 Green M22.5 P=0.5
G255 Green M25.5 P=0.5
G270 Green M27.0 P=0.5
G305 Green M30.5 P=0.5
Y225 Yellow M22.5 P=0.5
Y255 Yellow M25.5 P=0.5
Y270 Yellow M27.0 P=0.5
Y305 Yellow M30.5 P=0.5
R225 Red M22.5 P=0.5
R255 Red M25.5 P=0.5
R270 Red M27.0 P=0.5
R305 Red M30.5 P=0.5

○Please contact us for different filters, not listed on the catalogue.
